PM-50 graphical panel meters connect you to the information that matters, where and when you need it most.
As the newest addition to Red Lion's award-winning portfolio of panel meters, the PM-50 offers built-in Wi-Fi connectivity and provides access to critical workflow and data from the confines of the plant floor to create a smarter plant floor. Wired connectivity is also an option via Ethernet and Modbus.
- 3.5" and 4.3"Graphical Display
- Full Color, Touchscreen
- Analog and Digital Models
- 1/16 and 1/8 DIN Panel Cut-out
The PM-50 is available as a 3.5-inch or 4.3-inch graphical touchscreen display. Using simple "swipe" technology, users can easily switch between relevant screens and receive comprehensive operational data for monitoring equipment and production. Visual alerts notify the user that immediate action is necessary, either on the unit itself or via the PM-50 app, available on Google Play or Apple Store.
Panel meters should be evolving just like other automation devices, providing a clear and easy installation and upgrade path.
With the PM-50, this starts at the installation of the device itself, as it was built to easily fit into where your old panel meter was.- Its intuitive nature and built-in Wi-Fi makes it easy to get data from the device to your smart device using the Red Lion app.
- It also offers wired connectivity via Ethernet and Modbus. In addition, it offers wireless communication via Wi-Fi, meaning you won’t have to run additional wires to connect devices.
This will allow you to create a “data infrastructure” within your workspace.
Red Lion PM-50 Panel Meters
Compact in Size, but Big in Benefits...
In addition to Ethernet, Modbus/RS485, and RS232 communication, you can take advantage of Wi-Fi for a truly wire-free connectivity.
Add capability by stacking modules to your PM-50. The field installable modules provide output, communications, and AC power functionality when needed.
An on-device programming wizard gets set-up of the PM-50 started. Alternatively, you can program it using mobile apps or from a web browser.
Simply replace any meter in an 1/8 or 1/16 DIN panel cutout and turn on the Wi-Fi. Welcome to your connected smart factory floor.
Large, best-in-class displays - either 3.5" or 4.3" - with vibrant, user-selectable graphics present critical operational data for at-a-glance insights.
Choose from a library of intuitive screens, customizing meter elements to reveal your most important data with minimal interaction.
Today’s manufacturing environment is changing quickly and there is a greater need for data visibility, connectivity, and collection. So, when developing this next-generation panel meter, the team at Red Lion challenged themselves to create a product that would help solve these challenges and allow manufacturers to take additional steps in creating a smarter factory floor. The PM-50, with its innovative graphical display, does just that - allowing for more efficient processes, improved uptime, and lower operational costs.
- Rod Smith, Senior Director of Product Management for Red Lion
PM-50: The Panel Meter Reimagined
Find out how one easy install can change everything. Graphical Panel Meter, PM-50 easily integrates into your existing system. With simple setup and wire-free connectivity via Wi-Fi, PM-50 transforms your plant floor into a smart floor.
And, did you know that Red Lion has a Panel Meter Trade-Up Program?
Your IES team can help you determine if you're eligible
to receive Red Lion's new PM-50 for free!*
Connect with Your IES Team to Get Started
*Terms and Conditions apply. Offer availability depends on the location. All requests are subject to final approval by Red Lion Controls, Inc.
On-Board Features include:
- Smart device connectivity
- Wi-Fi and Modus communications
- Universal inputs
- Dual solid state outputs
- Display color change and status notification
- Start-up wizard/ programming assistance
- App for programming and monitoring
- Modular construction for additional capability
